VXR Series
Hi-Rel COTS DC-DC converters designed for demanding avionics and military applications, featuring rugged epoxy encapsulation, high efficiency, and an ultra-wide input voltage range to withstand extreme environments.
Key Features
- Isolated DC-DC Converters
- EMI Filters
- 7-250 Watts
- Wide Input Voltage Range
- -55 °C to +105 °C
- High Efficiency
- Rugged Environmental Screening
Hi-Rel COTS DC-DC Converters
VPT’s VXR Series of high-reliability COTS DC-DC converters are designed and engineered to excel in demanding commercial avionics and military applications, including unmanned systems. Built for harsh environments, the VXR Series withstand severe vibration, shock, and temperature cycling, thanks to their fully encapsulated epoxy packaging, that ensures reliable performance from -55 °C to +105 °C.
With high efficiencies, an ultra-wide input voltage range, and advanced packaging technology, the VXR Series delivers next-generation power solutions for rugged duty applications. The VXR Series of isolated DC-DC converters is the latest and most advanced offering in VPT’s extensive line of high reliability COTS products.
Explore the VXR Series full specifications and qualifications below.
Patented V-SHIELD® Packaging Technology
VPT's patented V-SHIELD® packaging is an advanced epoxy encapsulation solution featuring a six-sided metalized shield for enhanced EMI protection and dual-sided conduction cooling for improved thermal management. It offers superior chemical resistance and durability, making it ideal for rugged military and aerospace applications.
Wide Input Voltage Range
The VXR Series features a wide input voltage range of 9-60V, offering increased system flexibility, enhanced reliability, and can support multiple designs. For more details, please refer to individual datasheets or contact our sales team.
Hi-Rel COTS Environmental Screening Options
Please review VPT's Hi-Rel COTS environmental screening options for the VXR Series. Custom environmental screening may be performed to meet specialized needs. Please contact a sales representative concerning different environmental screenings.
Related Information
All ResourcesSelecting the Correct Level of DC-DC Converter for Your Application
VXR Series Output Voltage Ripple Reduction
Product and Quality Assurance Overview for VPT Hi-Rel COTS DC-DC Converters and Accessory Products
Learn How to Properly Utilize your EMI Filter Presentation
VXR Series Products
45 Results
Product | Datasheet | Product Type | TID | SEE | Temp. Range | Vin | Output Power/Current | Output Voltage | # Of Outputs | Series Image |
|---|---|---|---|---|---|---|---|---|---|---|
| VXR250-2805S | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 250 W | 5 V | 1 |  |
| VXR250-2812S | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 250 W | 12 V | 1 | |
| VXR250-2815S | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 250 W | 15 V | 1 | |
| VXR250-2828S | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 250 W | 28 V | 1 | |
| VXR250-283R3S | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 165 W | 3.3 V | 1 | |
| VXR100-280505D | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 100 W | * 5 V | 2 |  |
| VXR100-281212D | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 100 W | * 12 V | 2 | |
| VXR100-281515D | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 100 W | * 15 V | 2 | |
| VXR100-283R33R3D | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 100 W | * 3.3 V | 2 | |
| VXR100-2805S | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 100 W | 5 V | 1 |  |
| VXR100-2807S | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 100 W | 7 V | 1 | |
| VXR100-2812S | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 100 W | 12 V | 1 | |
| VXR100-2815S | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 100 W | 15 V | 1 | |
| VXR100-2818S | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 100 W | 18 V | 1 | |
| VXR100-283R3S | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 100 W | 3.3 V | 1 | |
| VXR30-280505D | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 30 W | * 5 V | 2 |  |
| VXR30-281212D | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 30 W | * 12 V | 2 | |
| VXR30-281515D | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 30 W | * 15 V | 2 | |
| VXR30-283R33R3D | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 30 W | * 3.3 V | 2 | |
| VXR30-2805S | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 30 W | 5 V | 1 |  |
| VXR30-2807S | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 30 W | 7 V | 1 | |
| VXR30-2812S | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 30 W | 12 V | 1 | |
| VXR30-2815S | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 30 W | 15 V | 1 | |
| VXR30-283R3S | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 30 W | 3.3 V | 1 | |
| VXR15-280505D | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 15 W | * 5 V | 2 |  |
| VXR15-281212D | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 15 W | * 12 V | 2 | |
| VXR15-281515D | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 15 W | * 15 V | 2 | |
| VXR15-283R33R3D | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 15 W | * 3.3 V | 2 | |
| VXR15-2805S | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 15 W | 5 V | 1 |  |
| VXR15-2812S | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 15 W | 12 V | 1 | |
| VXR15-2815S | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 15 W | 15 V | 1 | |
| VXR15-283R3S | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 15 W | 3.3 V | 1 | |
| VXR7-280505D | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 7 W | * 5 V | 2 |  |
| VXR7-281212D | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 7 W | * 12 V | 2 | |
| VXR7-281515D | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 7 W | * 15 V | 2 | |
| VXR7-2805S | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 7 W | 5 V | 1 |  |
| VXR7-2812S | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 7 W | 12 V | 1 | |
| VXR7-2815S | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 7 W | 15 V | 1 | |
| VXR7-283R3S | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 7 W | 3.3 V | 1 | |
| VXR7-283R33R3D | Datasheet | DC-DC Converters | NA | NA | -55°C to +105°C | 28 V | 7 W | * 3.3 V | 2 | |
| VXRF50-28 | Datasheet | EMI Filters | NA | NA | -55°C to +105°C | 28 V | 50 A | 28 V | 1 |  |
| VXRF20-28 | Datasheet | EMI Filters | NA | NA | -55°C to +105°C | 28 V | 20 A | 28 V | 1 |  |
| VXRF10-28 | Datasheet | EMI Filters | NA | NA | -55°C to +105°C | 28 V | 10 A | 28 V | 1 |  |
| VXRF5-28 | Datasheet | EMI Filters | NA | NA | -55°C to +105°C | 28 V | 5 A | 28 V | 1 |  |
| VXRF2-28 | Datasheet | EMI Filters | NA | NA | -55°C to +105°C | 28 V | 2 A | 28 V | 1 |  |
