VXR100-2800S Series

VXR100-2807S DC-DC Converter

The VXR Series of isolated DC-DC converters is the latest and most advanced offering in VPT’s extensive line of high reliability COTS products. Building on a proven design heritage, the VXR series features high efficiency, an ultra-wide input voltage range and next-generation packaging. Providing a wide 9 V to 60 V input, along with VPT’s standard full feature set and industry-leading performance, the VXR family is optimized for a broad range of applications from military ground vehicles to commercial and military aircraft.

Select Output Voltage

Output Power/Current100 W
Output Voltage7 V
Nominal Input Voltage28 V
Continuous Input Voltage Range11 V to 60 V
# of Outputs1
Temperature Range-55°C to +105°C
EMI FilterVXRF10-28
Thermal PadsTP-016 or TP2-016
