VPT Logo
SVRFL2800 D

SVRFL2800D Series

SVRFL2805D DC-DC Converter

The SVRFL Series of space qualified DC-DC converters is specifically designed for the harsh radiation environment of space applications and is designed in accordance with Aerospace TOR requirements. Performance is guaranteed through the use of hardened semiconductor components, radiation lot acceptance testing (RLAT) of non-hardened components, and analysis.

View DatasheetRequest a QuoteContact Sales

Select Output Voltage

Output Power/Current100 W
Output Voltage±5 V
Nominal Input Voltage28 V
Continuous Input Voltage Range18 V to 40 V
# of Outputs2
Total Dose (TID)100 krad(Si)
Single Event Effects (SEE)85 MeV/mg/cm²
Temperature Range-55°C to +125°C
SMD#5962R13234
EMI FilterSVRMC28
Thermal PadsTP-001 or TP-019
SVRFL2805D

Request a Quote

Please request a quote for lead time.

This product is offered with higher screening levels, please contact sales to learn more.

Request Now
