Avionics, Military & Space Point of Load DC-DC Converters

VPT’s point-of-load converters can be used alone or in conjunction with either the DV Series of hybrid DC-DC converters or the SV and SVR Series of space DC-DC converters as part of VPT’s High Efficiency, Reliability Optimized (HERO) Power Systems.

Non-isolated, synchronous, buck regulated converters step down the voltage at the point of end use. These hi-rel POL modules are ultra light weight, have a tiny footprint, and offer incredible high efficiency to provide designers with a smaller, more affordable point-of-of use power converter option.

VPT’s point-of-load converters are the first in the world to be designed and built to military-grade reliability as defined in MIL-PRF-38534 Class H and Class K.



Max. Output Power (W)Model SeriesInput DC Voltage (V)Output Voltage (V)Efficiency
10WDVPL0503S4.0 - 5.50.8V to 3.4V92%
16WDVPL0505S3.0 - 5.50.8V to 3.4V96%
33WDVPL0510S4.5 - 5.50.8V to 3.4V95%
66WDVPL0520S4.5 - 5.5.8V to 3.4V90%
Max. Output Power (W)Model SeriesInput DC Voltage (V)Output Voltage (V)EfficiencySMD #
20WSVRGA0508S5V0.8V to 3.4V91%5962R13217
22WSVPL3R306SG3.3V or 5V0.8V to 3.8V95%5962R17215
33WSVGA0510S5V0.8V to 3.4V93%5962R12219
45WSVPL1209SG3.1V to 13.2V0.8V to 5V93%5962R17232
45WSVPL3R312SG3.3V or 5V0.8V to 3.8V93%5962R17217
50WSVGA0515S5V0.8V to 3.4V94%5962R12219
