VPT’s accessory modules provide a host of features in small size, light weight packages:
- 3 Series of products: Avionics/Military, Space, and COTS levels
- Meet MIL-STD-704A and MIL-STD-461 requirements with our EMI filters
- Smooth out your power line with our pre-conditioning module
- Control transient voltages with our EMI filters and transient suppression combo modules
- Control inrush current with our DVCL inrush current limiter
- Step down a 270V bus to 28V bus with our VPTHVM
Avionics and military grade modules, hybrid, hermetic technology, -55 °C to +125 °C
| Model Series | Input DC Voltage (V) | Max Output Current (A) | For Use With | Equivalent Industry P/N** |
|---|---|---|---|---|
| DVMSA | 0 - 50 | 0.8 | DVCH2800S, DVCH2800D | FMSA |
| DVMA28 | 0 - 50 | 1.0 | DVSA2800S, DVSA2800D, SVSA2800S, SVSA2800D | |
| DVMH28 | 0 - 50 | 2.0 | DVSB2800D, DVGF+2800T, DVHF+2800T, DVHF2800S, DVHF2800D, SVHF2800S, SVHF2800D | FMH-461, AFH-461 |
| DVMC28 | 0 - 50 | 4.0 | DVHV2800S, DVHV2800D, DVWR2800T, DVTR2800T, DVTR2800S, DVTR2800D, DVHE2800S, SVTR2800S, SVTR2800D | FMC-461, AFC-461 |
| DVMD28 | 0 - 50 | 7.0 | DVTR2800T, DVTR2800S, DVTR2800D, DVFL2800S, DVFL2800D | FMD-461 |
| DVME28 | 0 - 50 | 15.0 | DVFL2800S, DVFL2800D, SVFL2800S, SVFL2800D | FME-461, AME-461 |
| DV704A | 0 - 50 | 2.0A | DVSA2800S, DVSA2800D, DVHF+2800T, DVHF2800S, DVHF2800D, | FM704A, AF704A |
Radiation immune, space qualified, hybrid hermetic technology, -55 °C to +125 °C
| Model Series | Input DC Voltage (V) | Max Output Current (A) | For Use With | Equivalent Industry P/N** |
|---|---|---|---|---|
| SVRMH28 | 18-37.5 | 2 | SVRHF,SVRTR | FMH28 |
| SVRMC28 | 18-37.5 | 4 | SVRTR, SVRFL | FMC28 |
| SVRME28 | 18-37.5 | 10 | SVRFL | FME28 |
Hi-rel COTS EMI filters, six-sided metal packaging for efficient EMI shielding, -55 °C to +100 °C
| Model Series | Input DC Voltage (V) | Max Output Current (A) | For Use With | Equivalent Industry P/N** |
|---|---|---|---|---|
| VPTF1-28 | 0 - 50 | 1.0 | VPT5-2800S, VPT15-2800S, VPT15-2800D | None |
| VPTF3-28 | 0 - 50 | 3.0 | VPT5-2800S, VPT15-2800S, VPT15-2800D | None |
| VPTF10-28 | 0-50 | 10.0 | VPT5-2800S, VPT15-2800S, VPT15-2800D, VPT30-2800S, VPT30-2800D, VPT100-2800S, VPT100+2800S, VPT100+2800D | None |
| VPTF20-28 | 0 - 50 | 20.0 | VPT5-2800S, VPT15-2800S, VPT15-2800D, VPT30-2800S, VPT30-2800D, VPT100-2800S, VPT100+2800S, VPT100+2800D | None |
Inrush Current Limiter, avionics and military grade, hybrid, hermetic technology, -55 °C to +125 °C
| Model Series | Max Output Power (W) | Input DC Voltage (V) | OutputCurrent (A) | Use With |
|---|---|---|---|---|
| DVCL | 200 | 0 - 50 | 11 | DV Series DC-DC Converters and EMI Filters |
Control EMI and suppress transients in one efficient module, -55 °C to +125 °C
| Model Series | Input DC Voltage (V) | Max Output Current (A) | For Use With | Equivalent Industry P/N** |
|---|---|---|---|---|
| VPTc10-28 | -40 - +40 | 10.0 | VPT5-2800S, VPT15-2800S, VPT15-2800D, VPT30-2800S, VPT30-2800D, VPT100-2800S, VPT100+2800S, VPT100+2800D | None |
| VPTi10-28 | -40 - +40 | 10.0 | VPT5-2800S, VPT15-2800S, VPT15-2800D, VPT30-2800S, VPT30-2800D, VPT100-2800S, VPT100+2800S, VPT100+2800D | None |
| DVMN28 | 0 - 50 | 14.0 | DV200 |
Power Conditioning Module (VPTPCM) and Bus Converter Module 270V to 28V (VPTHVM). -55 °C to +100 °C.
| Model Series | Max Output Power (W) | Input DC Voltage (V) | Output Voltage (V) | Use With |
|---|---|---|---|---|
| VPTPCM-12 | 120 | 6 - 40 | 17 - 40 | DV and VPT Series DC-DC Converters |
| VPTHVM-270 | 200 | 180 - 350 | 26 - 30 | VPT Series DC-DC Converters |
**This is a potential pin-to-pin and functional compatible industry part number, however, there are some minor differences. Please contact a sales representative for more information.
