Hi-Rel COTS DC-DC Converters


VPT’s high-reliability COTS DC-DC converters are designed to meet the requirements of commercial avionics and military applications, including unmanned systems.

All of VPT’s product designs are based on decades of proven heritage, and deliver high-reliability at a cost within your program’s budget.

COTS products from VPT are available immediately from stock.

Features:

  • 5-250 watts
  • Wide input voltage range
  • Six-sided metal packages for maximum EMI shielding
  • Optional rugged epoxy V-SHIELD® encapsulated package with integral metalized EMI shield available for multiple models
  • -55 °C to +105 °C, no power derating necessary
  • High efficiency
  • Rugged environmental screening
  • MIL-STD-1275, MIL-STD-704A, MIL-STD-461, DO-160, ISO-9001, DEF-STAN 59-411
  • Testing to JESD22, MIL-STD-810, MIL-STD-883
  • J-STD-001, ISO-9001, IPC-A-610 Class 3 manufacturing
  • Products are available off-the-shelf and ready for fast delivery

*Features vary by product line. Please see the datasheets for detailed information.

Metal or encapsulated packaging for extreme temperatures in non-flight critical applications. -55 °C to +100 °C.
Max. Output Power (W)Model SeriesInput DC Voltage (V)Output Voltage (V)EMI Filter
5VPT5-2800S15-50Single 3.3, 5, 12, 15VPTF1, VPTF3
5VPT5-2800D15-50Dual ±5, ±12, ±15VPTF1, VPTF3
15VPT15-2800S15-50Single 3.3, 5, 12, 15VPTF1, VPTF3
15VPT15-2800D15-50Dual ±5, ±12, ±15VPTF1, VPTF3
30VPT30-2800S15-50Single 3.3, 5, 12, 15VPTF3
30VPT30-2800D15-50Dual ±5, ±12, ±15VPTF3
30VPT30-2800T9-80Triple 3.3, 5, 12, 15VPTF3-28, VPTF10-28
100VPT100-2800S16-40Single 3.3, 5, 12, 15, 28VPTF10, VPTF20,
VPTi10-28, VPTc10-28
100VPT100+2800S16-40Single 3.3, 5, 7, 12, 15, 28VPTF10, VPTF20,
VPTi10-28, VPTc10-28
100VPT100+2800D16-40Dual ±12, ±15VPTF10, VPTF20,
VPTi10-28, VPTc10-28
200VPTHVM-270 Bus Converter180-500Single 28N/A
250VPT250-2800S16-40Single 3.3, 5, 12, 15VPTF10, VPTF20,
VPTi10-28, VPTc10-28
Fully encapsulated epoxy packaging for rugged duty. -55 °C to +105 °C.
Max. Output Power (W)Model SeriesInput Voltage (V)Output Voltage (V)EMI Filter
7VXR7-2800S
9-60Single 3.3, 5, 12, 15VXRF2-28, VXRF5-28
7VXR7-2800D9-60Dual 3.3, 5, 12, 15VXRF2-28, VXRF5-28
15VXR15-2800S9-60Single 3.3, 5, 12, 15VXRF2-28, VXRF5-28
15VXR15-2800D9-60Dual 3.3, 5, 12, 15VXRF2-28, VXRF5-28
30
VXR30-2800S9-60
Single 3.3, 5, 7, 12, 15VXRF5-28, VXRF10-28
30VXR30-2800D9-60Dual 3.3, 5, 7, 12, 15VXRF5-28, VXRF10-28
100VXR100-2800S
11-60
Single 3.3, 5, 7, 12, 15, 18VXRF10-28, VXRF20-28
100VXR100-2800D
11-60Dual 3.3, 5, 12, 15VXRF10-28, VXRF20-28
Metal package with full internal potting for rugged duty. -55 °C to +100 °C. DV200-270 is 270Vin nominal.
Max. Output Power (W)Model SeriesInput DC Voltage (V)Output Voltage (V)EMI Filter
30DVST2800T15-50Triple. 3 outputs 3.3, 5, 12, 15 each independent Included
175DV200-270S160-400Single 3.3, 5, 12, 15, 28Contact Factory
175DV200-270D160-400Dual ±5, ±12, ±15 Contact Factory
200DV200-2800S16-50Single 3.3, 5, 12, 15DVMN
200DV200-2800D16-50Dual ±5, ±12, ±15 DVMN
Metal packaging for -40 °C to +100 °C in non-flight critical applications.
Max. Output Power (W)Model SeriesInput DC Voltage (V)Output Voltage (V)EMI Filter
5VHR5-2800S15-50Single 3.3, 5, 12, 15VHRF1-28, VHRF3-28
5VHR5-2800D15-50Dual ±5, ±12, ±15VHRF1-28, VHRF3-28
15VHR15-2800S15-50Single 3.3, 5, 12, 15VHRF1-28, VHRF3-28
15VHR15-2800D15-50Dual ±5, ±12, ±15VHRF1-28, VHRF3-28
30VHR30-2800S15-50Single 3.3, 5, 12, 15VHRF3-28
30VHR30-2800D15-50Dual ±5, ±12, ±15VHRF3-28
30VHR30-2800T9-80Triple 3.3, 5, 12, 15VHRF3-28, VHRF10
100VHR100+2800S16-40Single 3.3, 5, 7, 12, 15, 28VHRF10, VHRF20-28
100VHR100+2800D16-40Dual ±12, ±15VHRF10, VHRF20-28
