Ideal for applications such as commercial and military aircraft, weapons systems, and more, this line of DC-DC power converters is ready to fly when you are.
Save board space, weight, heat, and cost when you create an efficient power system using our isolated DC-DC converters plus our family of non-isolated, synchronous, buck regulated point of load DC-DC converters.
- 1-120+ watts
- MIL-PRF-38534 Class H
- -55 °C to +125 °C military temperature range, no power derating necessary
- 100% hermetic
- High efficiencies
- Thick-film hybrid technology for small size, light weight, and maximum reliability
- MIL-STD-461, MIL-STD-704A, DO-160, MIL-STD-883, ISO-9001
- DLA SMDs available for most modules
- Products are available off-the-shelf and ready for fast delivery
Isolated, thick-film hybrid converters for flight critical applications with extreme temperature requirements. -55 °C to +125 °C.
| Max. Output Power (W) | Model Series | Input DC Voltage (V) | Output Voltage (V) | EMI Filter | DLA SMD# | Equivalent Industry P/N* |
|---|---|---|---|---|---|---|
| 1.5 | DVCH2800S | 12-50 | Single 3.3, 5, 5.2, 12, 15 | DVMSA28 | 5962-09242 | MSA2800S ASA2800S |
| 1.5 | DVCH2800D | 12-50 | Dual ±5, ±12, ±15 | DVMSA28 | 5962-09243 | MCH2800D |
| 6 | DVSA2800S | 15-50 | Single 3.3, 5, 5.2, 12, 15 | DVMA28 DVMSA28 | 5962-03241 | MSA2800S ASA2800S |
| 6 | DVSA2800D | 15-50 | Dual ±5, ±12, ±15 | DVMA28 DVMSA28 | 5962-03242 | MSA2800D ASA2800D |
| 12.5 | DVSB2800D | 15-50 | Dual ±3.3, ±5 | DVMA28 | 5962-08205 | None |
| 12.5 | DVGF+2800T | 15-50 | Triple 3.3/±12, 3.3/±15 | DVMH28 DVMA28 | 5962-08205 | None |
| 15 | DVHV2800S | 15-50 | Single 3.3, 5, 5.2, 12, 15 | DVMA28 | 5962-11226 | MHV2800S AHV2800S |
| 15 | DVHV2800D | 15-50 | Dual ±5, ±12, ±15 | DVMA28 | 5962-11227 | MHV2800D AHV2800D |
| 15 | DVHF+2800T | 15-50 | Triple 5/±12, 5/±15 | DVMH28 DVMA28 | 5962-08206 | MHF+2800T |
| 15 | DVAB2800D | 15-50 | Dual ±5, ±12, ±15 | DVMH28 | Contact Factory | None |
| 20 | DVHF2800S | 15-50 | Single 1.9, 3.3, 5, 5.2, 12, 15 | DVMC28 DVMH28 | 5962-03243 | MHF2800S AHF2800S MHF+2800S |
| 20 | DVHF2800D | 15-50 | Dual ±5, ±12, ±15 | DVMC28 DVMH28 | 5962-03244 | MHF2800D AHF2800D MHF+2800D |
| 25 | DVWR2800T | 15-50 | Triple 3.3/±12V, 3.3/±15V | DVMC28,DVMH28 | Contact Factory | |
| 30 | DVTR2800T | 15-50 | Triple 5/±12, 5/±15 | DVMC28 DVMH28 | Contact Factory | MTR2800T ATR2800T MHV2800T AHV2800T |
| 40 | DVTR2800S | 15-50 | Single 2.5, 3.3, 5, 5.2, 12, 15 | DVMC28 DVMH28 | 5962-11224 | MTR2800S ATR2800S, AHV2800S |
| 40 | DVTR2800D | 15-50 | Dual ±5, ±12, ±15 | DVMC28 DVMH28 | 5962-11225 | MTR2800D ATR2800D MHD2800D AHV2800D |
| 50 | DVHE2800S | 16 - 40 | Single 1.9, 2.5, 3.3, 5V | DVMC28 | Contact Factory | N/A |
| 120 | DVFL2800S | 16-40 | Single 3.3, 5, 5.2, 12, 15 | DVMD28 | 5962-07243 | MFL2800S AFL2800S MFLHP2800S MOR2800S |
| 120 | DVFL2800D | 16-40 | Dual ±5, ±12, ±15 | DVME28 | 5962-07244 | MFL2800D AFL2800D MFLHP2800D MOR2800D |
Combine one isolated DC-DC converter with any of these point of load converters for reduced size, weight, heat and cost in your system. -55 °C to +125 °C , 5Vin nominal.
| Max. Output Power (W) | Model Series | Input DC Voltage (V) | Output Voltage (V) | DLA SMD # | Equivalent Industry P/N* |
|---|---|---|---|---|---|
| 10W | DVPL0503S | 4.0 - 5.5 | .8V to 3.4V | In process | N/A |
| 16W | DVPL0505S | 3.3 - 5.5 | .8V to 3.4V | 5962-09241 | N/A |
| 33W | DVPL0510S | 4.5 - 5.5 | .8V to 3.4V | In process | N/A |
| 66W | DVPL0520S | 4.5 - 5.5 | .8V to 3.4V | In process | N/A |
These converters include EMI filtering plus power conversion in one small, light weight, cost-effective package.
| Max. Output Power (W) | Model Series | Input DC Voltage (V) | Output Voltage (V) | EMI Performance Data | Equivalent Industry P/N* |
|---|---|---|---|---|---|
| 10 | DVEHF2800T | 15-50 | Triple 5/±12, 5/±15 | Contact Factory | MDI 3001Triple |
| 40 | DVETR2800S | 15-50 | Single 3.3, 5, 5.2, 5.7, 12, 15 | Contact Factory | MDI 3001Single |
| 40 | DVETR2800D | 15-50 | Dual ±5, ±12, ±15 | Contact Factory | MDI 3001Dual |
