Wide Input Voltage Range Rad Hard DC-DC Converters for Space

November 30, 2017 –  Today VPT announced that its SVR Series isolated DC-DC converters now offer an 18 to 40 V input range. The radiation-hardened SVR series of DC-DC converters is available in single and dual outputs and has been characterized to Total Ionizing Dose (TID) to 100 krad(Si), including Enhanced Low Dose Rate Sensitivity (ELDRS), and Single Event Effects (SEE) performance to 85 MeV-cm2/mg.

All SVR Series isolated DC-DC converters from VPT feature a wide input voltage range of 18 to 40, with a 50 V transient operation. The SVR Series isolated converters are highly efficient and utilize VPT’s proprietary radiation immune magnetic feedback technology. Features of the series include input undervoltage lockout, output soft start, current limit and short circuit protection. Additionally, the SVR Series is rated for full power operation up to 125° C.

“The demands of the space market continue to expand and change,” stated Monty Pyle, Vice President of Sales and Marketing for VPT. “Now more customers are seeking rad-hard solutions that require up to 40 V input, without the need to meet the stringent Aerospace TOR and MIL-HBK-1547 derating requirements. Since our SVR Series is MIL-PRF-38534 Class H and Class K qualified and available on DLA Standard Microcircuit Drawings (SMDs), the products offer the ideal efficiency and reliability for such customers.” Pyle explained that although the SVR Series isolated converters have always had 18 to 40 V range operation, the products were initially specified at 37.5 volts to support the Aerospace TOR and MIL-HBK-1547 requirements, for which the SVR Series was originally developed.

The first standard commercially available products from VPT were designed specifically for the harsh environment of space. Now with nearly 25 years of proven space heritage, VPT offers high reliability and high efficiency solutions to organizations around the world in industries which require reliable operation of each component for overall mission success.

VPT Introduces SVRSA Series of 6W Output Radiation Hardened DC-DC Converters

October 25, 2107 – Today VPT released its single and dual output SVRSA DC-DC converters to further expand its offering of radiation hardened high-reliability space products. Specifically designed for the harsh radiation environment facing space applications, the SVRSA Series has been characterized to Total Ionizing Dose (TID) to 100 krad(Si), including Enhanced Low Dose Rate Sensitivity (ELDRS), and Single Event Effects (SEE) performance to 85 MeV-cm2/mg.

SVRSA2800S in available flanged package

The SVRSA 6W output series offers a wide input voltage range of 18 to 40V, plus 50V transient operation, and is available in single output voltages of 3.3, 5, 12 and 15V and dual output voltages of ±5, ±12 and ±15V. The series topology is an isolated single-output flyback converter featuring VPT’s proprietary radiation immune magnetic feedback technology. Features of the SVRSA Series include input undervoltage lockout, output soft start, current limit and short circuit protection, and is rated for full power operation up to 125° C.

“We’ve leveraged our proven heritage in space product development in the design of the SVRSA Series, which follows our DLA-approved Radiation Hardness Assurance plan and is in accordance with Aerospace TOR requirements,” said Leonard Leslie, Vice President of Engineering for VPT. “This high efficiency hybrid series of DC-DC converters is aligned with programs headed for low Earth orbit or deep space.”

Comprehensive environmental screening for the SVRSA Series is per MIL-STD-883 as referenced in MIL-PRF-38534 including Class H and Class K. The DLA Land and Maritime has officially released the SVRSA Series standard microcircuit drawings (SMDs) under SMD family numbers 5962R15217 for the single output converters and 5962R15218 for the dual output converters.

“We’ve leveraged our proven heritage in space product development in the design of the SVRSA Series, which follows our DLA-approved Radiation Hardness Assurance plan and is in accordance with Aerospace TOR requirements,” said Leonard Leslie, Vice President of Engineering for VPT. “This high efficiency hybrid series of DC-DC converters is aligned with programs headed for low Earth orbit or deep space.”

Comprehensive environmental screening for the SVRSA Series is per MIL-STD-883 as referenced in MIL-PRF-38534 including Class H and Class K. The DLA Land and Maritime has officially released the SVRSA Series standard microcircuit drawings (SMDs) under SMD family numbers 5962R15217 for the single output converters and 5962R15218 for the dual output converters.

The SVRSA Series single and dual output DC-DC converters are available for immediate sale. Additional information, mechanical drawings and performance charts can be found within VPT’s space product information pages.

VPT Efficiency Tips Featured in Electronics Magazine

July, 2017 – The most recent issue of the UK’s Electronics Magazine featured an article by VPT’s Steve Butler, Director of Advanced Product Development, on improving power conversion efficiency through advanced topologies for military applications. Butler details proven electronic design possibilities for simplifying power system design yet improving overall performance while meeting multiple military specifications. Please see the full article, titled “The Power Behind Military Electronics”  here

VPT Expands its VXR High-Reliability Line

BLACKSBURG, VA, June 6, 2017 – VPT, Inc. (VPT®), a HEICO company (NYSE:HEI.A) (NYSE:HEI), today released its dual output VXR Series DC-DC converters to augment its offering of advanced high-reliability COTS products. Optimized for a broad range of programs from military ground vehicles to commercial and military aircraft, the VXR Series products feature wide input voltage ranges and advanced packaging technology for superior operation in harsh environments. The VXR Series now includes both single and dual output offerings from 7 Watts to 100 Watts as well as 2 to 20 Amp EMI filters.

The VXR Series dual output DC-DC converters feature two independently controlled and isolated outputs which provide zero cross-regulation. Each output can be configured as positive, negative or stacked allowing for a broad range of output voltage configurations.  Additionally, the output voltages can be ordered as unmatched pairs as a standard product option providing a vast range of flexibility within an overall power system design.

“The entire VXR Series of products has a robust mechanical design that is highly efficient over a wide input voltage range including significant input transient capability,” said Jeremy Ferrell, VPT’s Manager of Standard Product Engineering. “Also, the proprietary two-stage topology provides incredibly fast transient response time without the use of optoisolators.”

In addition to high efficiency and high reliability, the VXR Series features its proprietary V-SHIELD® advanced packaging technology. V-SHIELD® ­­­­­­­­­­­­­­­ is an integral epoxy encapsulation which incorporates EMI shielding and dual-sided thermal conduction. It is highly resistant to chemical, solvent and salt environments and is fully compatible with high-volume manufacturing processes including wave solder, cleaning solvents, high-pressure sprays and aqueous wash.

An additional update to the VXR Series family of DC-DC converters is the capability of the single output converters to now meet the 100 Volt surge requirement of MIL-STD-1275 as well as DO-160. The 100 Volt surge operation is achieved without adding external components to the converters.

“Programs requiring high reliability and cutting edge performance while potentially operating in harsh, taxing environments are prime candidates for the efficiency and durability of the VXR Series of DC-DC converters and EMI filters,” said Monty Pyle, VP of Sales and Marketing. “The extension of this product family illustrates our commitment to innovation based on proven design heritage.”

The VXR Series single and dual output DC-DC converters and VXR Series EMI filters are available for immediate sale. Individual unit prices begin at $100 (USD) for volume quantities. Additional information on the VXR Series and specific product datasheets can be found within VPT’s COTS product information on www.vptpower.com.

HEICO on Institutional Investor Magazine’s Most Honored Companies List. HEICO CEO Laurans Mendelson Named Best CEO in Aerospace & Defense

January 12, 2016 – VPT’s parent company, HEICO, announced today that it has been named on the prestigious list of Most Honored Companies by Institutional Investor Magazine. The highly-regarded publication has also named HEICO CEO, Laurans A. Mendelson, Best CEO in the Aerospace and Defense Electronics sector. The results are based on a survey of over 3,000 portfolio managers and analysts considering characteristics of a strong management team. The press release can be viewed here.

VPT’s V-SHIELD Earns Top Level Award from Military & Aerospace Electronics Innovators Award Program

November 15, 2016 – VPT today announced today that its V-SHIELD® packaging technology has been recognized by the judges of the 2016 Military & Aerospace Electronics Innovators Awards program with the highest, platinum level award. The platinum level recognizes military and aerospace electronics featuring a superb innovation, characterized by a groundbreaking approach to meeting a need, a new level of performance, efficiency and/or ease-of-use.

V-SHIELD® is a proprietary, patent-pending, fully encapsulated epoxy packaging solution for VPT’s DC-DC converters and EMI filters that is highly resistant to chemical, solvent and salt environments and is fully compatible with high volume manufacturing processes including wave solder, cleaning solvents, high pressure sprays and aqueous wash processes. It features a unique integral six-sided metalized shield to improve system EMI compatibility. It also simplifies system thermal design with dual-sided conduction cooling coupled with reduced power dissipation. V-SHIELD® packaging combines the reduced radiated emissions advantage of metal packaging with the water/chemical resistivity of epoxy packaging, allowing for superior performance at a COTS level price.

“We are honored that our V-SHIELD® packaging has received the highest level award by the Military & Aerospace Electronics Innovators Awards judges,” said Jeremy Ferrell, Manager of Standard Product Engineering for VPT. “V-SHIELD® packaging was designed for applications such as military ground vehicles as well as commercial and military aircraft that must operate within harsh and rugged environments including severe vibration, shock and temperature cycling. We thrive on creating innovations while maintaining product reliability and improving operational efficiencies.”

The Military & Aerospace Electronics Innovators Awards program was developed to recognize the most innovative solutions in military and aerospace technology products and systems, as determined by a panel of senior, third-party, expert judges. Alan Bergstein, publisher of Military & Aerospace Electronics (www.militaryaerospace.com), said, “This prestigious program allows Military & Aerospace Electronics to celebrate and recognize the most innovative products and services in the military electronics industry. Our 2016 Honorees are an outstanding example of companies who are making an impact.”

VPT Provides High Reliability Parts for NASA Mission

September 19, 2016 – The Roanoke Times recently covered the involvement of VPT in the OSIRIS-REx asteroid mining mission. VPT President John Hodock explained the significance of high reliability DC-DC converters for space programs as well as the history of VPT’s success. See the complete article for more detailed information.

VME Power Systems article in Aerospace & Defense Technology

June 30, 2016 – An article written by Steve Butler, VPT’s Director of Advanced Product Development, is featured in the June issue of Aerospace & Defense Technology magazine published by Tech Briefs. The article, titled “Designing VME Power Systems with Standard Modules” explains the potential for rapid development of custom VME solutions through the utilization of standard DC-DC converters and EMI filters. Within the article, Butler covers the benefits of the “custom using off-the-shelf modules” approach. Additionally, he details how designing the custom VME power systems can meet multiple military engineering standards and performance specifications.

Read the complete article.

VPT Adds Industrial Level VHR Series DC-DC Converter Line

BLACKSBURG, VA, June 22, 2016VPT, Inc. (VPT®), a HEICO company (NYSE:HEI.A) (NYSE:HEI), today released the VHR Series of industrial level DC-DC converters and EMI filters. Available in models ranging from 5 to 100 watts, the VHR Series of DC-DC converters provides customers with VPT’s renowned levels of product reliability for powering non-flight-critical programs in military, avionics, and unmanned systems as well as manufacturing equipment and controls.

“Engineers aren’t looking for a ‘one converter fits all’ solution, so VPT supplies a wide range of high reliability standard products that best match specific application requirements,” said VP of Sales and Marketing, Monty Pyle. “Just as space programs utilize converters designed for rigid MIL specs and radiation exposure, programs on the other end of the spectrum are aligned to solutions, like the VHR Series, that are cost effective and highly reliable without requiring the extensive environmental screening that is necessary for flight-critical programs.”

The VHR Series design leverages VPT’s decades of experience in proven military, aerospace and defense solutions. For budget-driven programs, the series offers a wide input voltage range for nominal 28 volt input, an average 85% efficiency and low input and output ripple for reliable operational success, even in rugged environments.

Designed to operate at full-load over a wide temperature range of -40°C to +100°C, the VHR Series also offers fixed frequency operation, soft-start, magnetic feedback, inhibit and current-limit protection. Additionally, the VHR Series includes companion EMI filters ranging from 1 to 20 amps.

The VHR Series of DC-DC converters and EMI filters are available for immediate sale. Unit prices begin at $65 (USD) for volume quantities. Additional information on the VHR Series can be found by viewing the VHR Series product page and the VHR datasheets.

HEICO Ranked One of 100 Most Trustworthy Companies in America

June 8, 2016 – VPT’s parent company, HEICO Corporation (NYSE:HEI.A) (NYSE:HEI), was recently selected by Forbes as one of the 100 Most Trustworthy Companies in America based on accounting and governance practices. This recognition, which identifies American companies that most consistently demonstrate transparent accounting practices and solid corporate governance, is HEICO Corporation’s 11th recognition by Forbes in the past several years. Within its category of MID CAP companies between $1 billion and $5 billion in revenue, HEICO Corporation joined the ranks of American Eagle Outfitters. Logitech International and Virgin America.

EE Times Europe Covers VPT’s High Temp Product Announcement

May 13, 2016 – The European division of EE Times covered VPT’s recent announcement of its launch of the HTD Series of DC-DC converters which are specifically designed for harsh and extreme temperature environments. The complete article is linked here.

VPT Releases High Temperature Product Line

HTD Series Hybrid DC-DC Converters Designed for Extreme Environments up to 185°C

ALBUQUERQUE, NM – May 10, 2016 – VPT, Inc. (VPT®), a HEICO company (NYSE:HEI.A) (NYSE:HEI), released the HTD Series of DC-DC converters at the iMAPS International Conference on High Temperature Electronics, HiTEC 2016. The HTD Series of DC-DC converters, leveraging VPT’s high reliability power supply design heritage, is specifically designed for harsh and extreme temperature environments including downhole oil and gas, MWD/LWD and wireline logging tools, aircraft engine electronics and other industrial applications requiring reliable operation in high temperatures.

The HTD isolated 1.5 Watt DC-DC converter operates from -55°C to 155°C and the HTD non-isolated DC-DC converters operate from -55°C to 185°C. Each model has dual outputs and is designed using thick film hybrid microcircuit technology, bare semiconductor die integrated with passive components and thick film conductors
on a ceramic substrate. Within the HTD design, component-attach and die bonding are optimized for high temperature life, and hermetic metal packaging protects internal components for long-term reliability.

VPT’s Director of Advanced Product Development, Steve Butler, said, “We developed these products specifically for reliable performance in settings which are both high-temperature and rugged, testing them extensively for operating life and temperature cycling over the full temperature range as well as for mechanical shock and vibration.”

“Electronics for downhole and near-engine applications must operate consistently within brutal environments,” said Vice President of Sales & Marketing, Monty Pyle. “With VPT’s expertise in power supplies for space, avionics and rugged military applications, developing products for these high-temperature applications is a natural extension of our high reliability product lines.”

The HTD Series of DC-DC converters are available for immediate sale. Unit pricing begins at $700-800 (USD) for volume quantities, depending on product model. Custom versions are also available. Additional information on the HTD Series and specific product datasheets can be found at www.vptpower.com.



VPT Presents at Space Parts Working Group 2016

April 20, 2016 – VPT’s Director of Engineering, Leonard Leslie, presented yesterday to the attendees of the 45th annual Space Parts Working Group.  The Space Parts Working Group (SPWG) is sponsored by The Aerospace Corporation, in cooperation with the U.S. Air Force Space and Missile Systems Center (SMC) and the National Reconnaissance Office. SPWG is an unclassified, international forum for disseminating information to the aerospace industry and for resolving problems with high-reliability electronic piece parts for space applications. More information can be found on the event website.

Virginia State Leaders Visit VPT

April 13, 2016- We are proud to have hosted a headquarters facility visit from respected state leaders today. Virginia House Delegate Terry Austin, Virginia Secretary of Commerce Maurice Jones, and Director of the Virginia Space Grant Consortium Mary Sandy met with VPT’s CEO Dr. Dan Sable, Director of Engineering Leonard Leslie, as well as Shawn Graham, VPT’s Chief Operations Officer and Executive Director of Quality.

The Virginia Space Grant Consortium (VSGC) is a coalition of five Virginia colleges and universities, NASA, state educational agencies, Virginia’s Center for Innovative Technology, and other institutions representing diverse aerospace education and research. Headquartered on the Virginia Tech Corporate Research Center campus, VPT has long supported aerospace engineering educational efforts in the state, and we are grateful to be able to contribute to the growth of the aerospace industry as a whole.

VA House Delegate Terry Austin, VPT's Dr. Dan Sable, VA Secretary of Commerce Maurice Jones, Virginia Space Grant Consortium Director Mary Sandy

VPT Design Tips in Military Embedded Systems Magazine

December 21, 2015 – Steve Butler, VPT’s Director of Advanced Product Development, recently shared information with the readers of Military Embedded Systems on advanced power conversion topologies for military programs. The article details potential design approaches that meet military standards for wide input voltage range while increasing power conversion efficiency and decreasing heat, size and weight. Please see Military Embedded Systems magazine to read the complete article.

VPT Supports Virginia Tech’s Electrical & Computer Engineering Department With Donation to AMP Lab

November 12, 2015 – VPT recently provided a $25,000 donation to Virginia Tech’s Electrical & Computer Engineering Department in support of its Autonomous Mastery Prototyping Lab (AMP Lab).

The AMP Lab offers a creative, practical, hands-on learning environment for Electrical and Computer Engineering students, staff, and faculty at Virginia Tech. In addition to fostering mentorship for undergraduates, the AMP Lab offers programs in circuit design, PC board layout, soldering, and lab safety.

VPT has supported the engineering programs at Virginia Tech for many years. VPT’s CEO, Dr. Dan Sable has served as the chairman of the Virginia Tech Electrical and Computer Engineering Department Industrial Advisory Board where he was instrumental in founding the Space Science and Engineering Research program. This is VPT’s fifth donation to Virginia Tech’s engineering programs.

Pictured: Dr. Luke Lester, Electrical & Computer Engineering Department Head at Virginia Tech (left), Dr. Dan Sable, CEO of VPT (middle), and John Hodock, President of VPT (right).

Military Embedded Systems Editor’s Choice: SVR Series

June 25, 2015 - John McHale, the editorial director of Open Systems Media and publisher of The McHale Report on the defense electronics industry, selected VPT’s SVR Series for the recent Military Embedded Systems magazine “Editor’s Choice Products” report. The article, titled “A Power Solution for Space Applications,” covers the military and TOR qualifications of the SVR Series along with the general product features including radiation exposure performance .

Read the complete article.



VPT Presents at Space Tech Expo 2015

May 21, 2015 – Yesterday at Space Tech Expo in Long Beach, CA, VPT’s Senior Design Engineer Brandon Witcher presented on the topic of power challenges of modern space systems. Specifically speaking to space system processor board designers, Witcher discussed the tight regulation and multiple complex requirements involved in current data-intensive space payloads. He also presented distributed power solutions that address the vast operating conditions and varied feature requirements. Please see Space Tech Expo for more information on this annual event.

VPT Adds VXR Series to Hi-Rel COTS Product Line

Wide Input Voltage Range and Advanced Packaging Technology for Superior Operation in Harsh Environments

May 5, 2015 - VPT, Inc. (VPT®), a HEICO company (NYSE:HEI.A) (NYSE:HEI), launched its new VXR Series of DC-DC Converters and EMI Filters today at the annual Association for Unmanned Vehicle Systems International (AUVSI) conference being held in Atlanta, Georgia. The VXR Series of DC-DC Converters and EMI Filters represent VPT’s most advanced offering of its extensive line of high-reliability COTS DC-DC Converters and accessory products. Available in models ranging from 7 to 100 Watts with an industry leading wide continuous input voltage range from 9 to 60 VDC and transient operation from 6 to 80 VDC, the VXR Series is optimized for a broad range of applications from military ground vehicles to commercial and military aircraft, including the unique power needs of unmanned aerial and ground systems.

The VXR Series utilizes VPT’s patent-pending advanced packaging technology. This proprietary encapsulation process incorporates EMI shielding and dual-sided thermal conduction. The integral epoxy encapsulated packaging is highly resistant to chemical, solvent and salt environments and is fully compatible with high-volume manufacturing processes including wave solder, cleaning solvents, high-pressure sprays and aqueous wash.

“The VXR Series of products is reliability and efficiency focused, utilizing a low-noise, fixed frequency wide input voltage range topology,” said Jeremy Ferrell, VPT’s Manager of Standard Product Engineering. “We achieved this high efficiency over a wide input voltage range with a proprietary precision-controlled synchronous rectification topology. The high efficiency design in-turn reduces the thermal management requirements. We also incorporated a proprietary control loop design that provides a fast transient response without the use of optoisolators.”  Ferrell added, “For customers with noise sensitive applications, we developed the VXR EMI Filter Series with current ratings from 2 to 20 Amps that were specifically designed to meet specific MIL-STD-461 and DO-160 conditions when used with our VXR Series DC-DC Converters.”

The VXR Series of DC-DC Converters and EMI Filters are available for immediate sale. Individual unit prices begin at $100 (USD) for volume quantities. Please see specific product pages and datasheets for more information.



VPT Presents at Space Parts Working Group 2015

April 29, 2015 -  Dr. Dan Sable, VPT’s CEO and Leonard Leslie, VPT’s Director of Engineering presented company updates and space product developments to the attendees of Space Parts Working Group yesterday in Torrance, CA. The Space Parts Working Group (SPWG) is sponsored by The Aerospace Corporation, in cooperation with the U.S. Air Force Space and Missile Systems Center (SMC) and the National Reconnaissance Office. Now in its 44th year, SPWG is an unclassified, international forum for disseminating information to the aerospace industry regarding electronic piece parts for space applications. Please see the Space Parts Working Group website for more information.
